Road Bikes Race Ultimate CF SL

Ultimate CF 7

¥18,200

Our best-value carbon race bike
Renowned Ultimate ride quality
Shimano 105 12-speed mechanical groupset
50 mm Newman Advanced A.50 carbon wheels
Sleek, one-piece aero cockpit

Material: Carbon (CF)
Weight: 8.14 kg

Colour: White

Members only product.

Select frame size

What’s my size?
Find out in 3 steps

Delivery: Select frame size

Members only product.

Free Shipping

¥18,200

Delivery: Select frame size

Select frame size

Additional information

Current delivery times information. Read more

Not included:

Your bike already arrives 95% built. We give you the tools. And simple instructions. No technical skills needed.
That’s our quality promise – if you’re not 100% happy with your bike, we’re not happy either.
Learn more
Worried about maintaining your new bike? We have over 300 service locations making regular servicing quick and easy.

Learn more
Your bike arrives in our custom Bike Guard – built to absorb impacts in transit and keep every component locked in place. Tough, reusable, and ready to double as a stable stand for a fast setup.

Delivery: Select frame size

Highlights Ultimate CF 7

Race winning DNA for everyone

Pure road performance

The Ultimate CF offers the same high performance and pinpoint handling as the CF SLX and CFR, using a more accessible carbon fibre. This is the bike for road races, big days in the mountains and nailing that next personal best.

Designing the new Ultimate

Canyon engineer, Lukas Birr, explains the design and development process that went into creating the Ultimate; a road bike that delivers the perfect balance. Lightweight, stiff and aerodynamic. This is our classic road race bike, evolved.

Key features

Perfect Balance

When developing the Ultimate, our goal was to strike the perfect balance between lightness, stiffness, comfort, robustness, and aerodynamics. The result? The most balanced, best-value road bike on the scene.

A fast, lightweight carbon cockpit

This lightweight, stiff aero one-piece carbon cockpit features a race-inspired design for optimal control and precision. Ergonomically optimised drops make room for a tight, locked in thumb position for extra comfort and grip. Stay comfortable, stay aero, stay fast for the long haul.

Clean cockpit cable integration

With semi-integrated cables running beneath the cockpit before entering the frame, you get the advantages of a clean, efficient front end, and simple cockpit swaps in one.

High-grade carbon layup

The CF combines the cutting-edge innovations of the SLX and CFR platforms with a carbon layup that strikes the ideal balance between durability and value. By using specially selected fibres, the carbon layup sets the benchmark in terms of toughness.

Aerodynamically optimised

On the road, from just 14 kph, aerodynamic drag is the largest force holding you back. So we optimised the frame forms for minimum drag, through an exhaustive process of wind tunnel testing in collaboration with aero experts Swiss Side. We also integrated the headtube/fork area as much as possible for extra aero gains.

A watt-saving, comfortable carbon aero seatpost

With a clean, integrated clamp design and slender D-shaped seatpost to reduce air resistance, the Ultimate delivers efficiency and comfort in equal measure. Dialing in your perfect riding position is simple thanks to independent setback and tilt adjustment.

Components

Content is loading

Frame

Frame
- Canyon Ultimate CF
- Axle dimension 12x142 mm
- Tyre clearance 32 mm
- Material Carbon (CF)
Fork
- Canyon FK0141 CF Disc
- Axle dimension 12x100 mm
- Fork steer tube diameter 1 1/4"
- Tyre clearance 32 mm
- Material Carbon (CF)
- Weight 410 g
Seatpost Clamp
- Canyon EP2352-01 Saddle Clamp for saddles with 7x7 mm steel rails

Drivetrain

Rear Derailleur
- Shimano 105 RD-R7100 12s
- Weight 247 g
Front Derailleur
- Shimano 105 FD-R7100
- Weight 95 g
Cassette
- Shimano 105 R7101 11-34 12s
- Number of sprockets 12
- Range 11-34
Crank
- Shimano 105 Crankset
- Number of chainrings 2
Bottom bracket
- Shimano Pressfit BB-RS500
- Bottom bracket standard PF 86
- Weight 81 g
Chain
- Shimano Deore M6100

Brakes

Brake
- Shimano Flat Mount Adapter +20mm
Shift-/ Brake Lever
- Shimano 105 R7120 2s
- Number of pistons 2
- Weight 306 g
Shift-/ Brake Lever
- Shimano 105 R7120 12s
- Number of pistons 2
- Weight 332 g
Brake Rotor
- Shimano RT-CL300
- Size 160 mm
- Weight 190 g

Wheels

Front Wheel
- Newmen Advanced A.50
- Axle dimension 12x100 mm
- Rotor mount Center Lock
- Rim height 50 mm
- Inner width 23 mm
- Rim material Carbon
- Weight 670 g
Rear Wheel
- Newmen Advanced A.50
- Axle dimension 12x142 mm
- Rotor mount Center Lock
- Rim height 50 mm
- Inner width 23 mm
- Rim material Carbon
- Weight 798 g
Tyre
- Schwalbe One, 28mm
- Width 28 mm
- Weight 280 g
Thru Axle
- Canyon Steckachse
- Axle dimension 12x100 mm
Thru Axle
- Canyon Steckachse
- Axle dimension 12x142 mm

Cockpit

Cockpit
- Canyon CP30 Aerocockpit CF
- Material Carbon (CF)
- Weight 800 g
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color Black

Seat

Saddle
- Selle Italia Model A Greentech
- Gender Unisex
- Weight 315 g
Seatpost
- Canyon SP0094 CF
- Comfortable, compliant, lightweight carbon seatpost.
- Setback 10 mm
- Material Carbon (CF)
- Weight 118 g

Light

Lights
- Reflector Set

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- BAND 001-V01 BIKE CATEGORY 1
Manuals and Accessories
- Quick Start Guide
Manuals and Accessories
- Smallbox

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table
Frame size
Body Height in cm	≤ 166	166 - 172	172 - 178	178 - 184	184 - 190	190 - 196	≥ 196
a Seat Height in mm	622 - 722	652 - 752	682 - 782	712 - 812	742 - 842	772 - 872	802 - 902
b Seat Tube Length in mm	420	450	480	510	540	570	600
c Top Tube Length in mm	516	529	546	555	569	594	610
d Head Tube Length in mm	115	107	121	142	162	188	206
e Head Tube Angle	70°	71,2°	72,8°	73,25°	73,3°	73,5°	73,8°
f Seat Tube Angle	73,9°	73,9°	73,5°	73,5°	73,5°	73,5°	73,5°
g Chainstay Length in mm	405	410	410	410	413	415	415
h Wheel Base in mm	965	979	983	987	1.004	1.029	1.042
i Stack in mm	498	520	539	560	580	606	624
j Reach in mm	372	378	390	393	401	419	429
k Stand-over Height in mm	720	748	775	801	828	851	874
l Bottom Bracket Offset in mm	60	73	73	73	73	73	73
Effective stack in mm (O): Vertical distance between the bottom bracket and the hand position Learn more	565	592	608	629	651	676	694
Effective reach in mm (P): Horizontal distance between the bottom bracket and the hand position Learn more	522	516	539	553	570	599	619

Component geometry

Detailed geometry table
Frame size
Spacer in mm	18	18	18	18	18	18	18
Cockpit Dimensions in mm	80-370	90-370	90-390	100-390	110-410	110-410	120-430
Crank Length in mm	160,0	160,0	165,0	165,0	170,0	170,0	170,0
Chainring Size	52/36	52/36	52/36	52/36	52/36	52/36	52/36
Seat Post Length in mm	349	349	349	349	349	349	349
Maximum Seat Post Insertion Depth in mm	195	195	195	195	195	195	195
Minimum Seat Post Insertion Depth in mm	95	95	95	95	95	95	95
Wheel Size	28"	28"	28"	28"	28"	28"	28"
Disc Size in mm	160 / 160	160 / 160	160 / 160	160 / 160	160 / 160	160 / 160	160 / 160
Rim height in mm	50	50	50	50	50	50	50

Download PDF

Ultimate CF 7 support

Canyon Road Underseat Bag

¥159

Canyon Light Aero Cycling Socks

¥159

Canyon FIX Minitool 6+1

¥129

Canyon Bikestand

¥509

Bike classification

Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.

Disclaimer

Subject to technical modification without notice. Errors and omissions excepted.
